ANSI #50B Plain Bore Stainless Steel Sprockets
ANSI #50B Plain Bore Stainless Steel Sprockets
ANSI #50B Plain Bore Stainless Steel Sprockets

ANSI #50B Plain Bore Stainless Steel Sprockets

Model
#50 B Hub Sprockets

Item specifics

Meterial
Stainless Steel
Color
Silver
Surface Treatment
Blackening/Galvanizing/Phosphating
Accuracy
Precision teeth for optimum performance
Quality
Superior ANSI Sprocket
Interchangeability
Directly interchangeable with other brands

Review

Description

About #50B Plain Bore Stainless Steel Sprockets

The ANSI #50 B hub plain bore stainless steel sprockets are high-quality components designed for industrial applications that require precision engineering and reliable performance. Crafted from durable carbon steel materials, our #50B plain bore sprockets ensure optimal power transmission and efficient operation in various machinery setups. Trust CTS® expertise in chain sprockets manufacturing to deliver top-notch solutions tailored to your industrial needs.


For quotation or other information on plain bore sprockets, please contact us and we will be happy to help you.


Quality Assurance:

ISO9001: 2015 and GB/T24001-2016 / ISO14001: 2015.


Features

  • High-precision Sprocket
  • Durable Sprocket
  • Directly interchangeable with other brands
  • OEM Sprocket
ANSI #50B plain bore stainless steel sprockets dimension chart
#50B Plain Bore Stainless Steel Sprocket Technical Data
Pitch
5/8"
Roller φ
0.400"
Tooth width B1
0.343"
Part No.No. TeethTypeOutside Dia.（de）
inch		Bore Dia.（D1）
inch		 Hub Dia.（dm）
inch		LTB（A）
inch		Weight Lbs.
(Approx.)
MinMax
50B08SS8B1.880 5/8 5/81 1/8★1.25
50B09SS9B2.090 5/8 3/41 3/8★1.36
50B10SS10B2.300 5/8 7/81 9/16★1.48
50B11SS11B2.500 5/811 3/4★1.64
50B12SS12B2.710 5/81 1/41 63/64★1.83
50B13SS13B2.910 5/81  5/161 7/81.88
50B14SS14B3.110 5/81  7/162 1/811.13
50B15SS15B3.320 5/81 1/22 3/811.34
50B16SS16B3.520 5/81 3/42 1/211.51
50B17SS17B3.720 5/81 7/82 11/1611.74
50B18SS18B3.920 5/81 7/82 7/812.00
50B19SS19B4.120 3/42312.22
50B20SS20B4.320 3/42312.28
50B21SS21B4.520 3/42312.40
50B22SS22B4.720 3/42312.56
50B23SS23B4.920 3/42312.66
50B24SS24B5.120 3/4231 1/43.30
50B25SS25B5.320 3/4231 1/43.40
50B26SS26B5.520 3/4231 1/43.44
50B27SS27B5.720 3/4231 1/43.74
50B28SS28B5.920 3/4231 1/43.80
50B29SS29B6.120 3/4231 1/44.06
50B30SS30B6.320 3/423 1/41 1/44.56
50B31SS31B6.520 3/42 1/43 1/41 1/44.74
50B32SS32B6.720 3/42 1/43 1/41 1/44.96
50B33SS33B6.920 3/42 1/43 1/41 1/45.20
50B34SS34B7.120 3/42 1/43 1/41 1/45.14
50B35SS35B7.320 3/42 1/43 1/41 1/45.44
50B36SS36B7.520 3/42 1/43 1/41 1/45.64
50B37SS37B7.720 3/42 1/43 1/41 1/45.90
50B38SS38B7.920 3/42 1/43 1/41 1/46.08
50B39SS39B8.120 3/42 1/43 1/41 1/46.30
50B40SS40B8.320 3/42 1/43 1/41 1/46.50
50B41SS41B8.520 3/42 1/43 1/41 1/46.64
50B42SS42B8.720 3/42 1/43 1/41 1/46.96
50B43SS43B8.910 3/42 1/43 1/41 1/47.06
50B44SS44B9.110 3/42 1/43 1/41 1/47.58
50B45SS45B9.310 3/42 1/23 3/41 1/48.58
50B46SS46B9.510 3/42 1/23 3/41 1/48.22
50B47SS47B9.710 3/42 1/23 3/41 1/48.48
50B48SS48B9.91012 1/23 3/41 1/49.28
50B49SS49B10.11012 1/23 3/41 1/49.22
50B50SS50B10.31012 1/23 3/41 1/49.88
50B51SS51B10.51012 1/23 3/41 1/49.70
50B52SS52B10.71012 1/23 3/41 1/410.24
50B53SS53B10.91012 1/23 3/41 1/410.48
50B54SS54B11.11012 1/23 3/41 1/411.00
50B55SS55B11.31012 1/23 3/41 1/410.93
50B56SS56B11.50012 1/23 3/41 1/411.50
50B57SS57B11.70012 1/23 3/41 1/412.00
50B58SS58B11.90012 1/23 3/41 1/411.82
50B59SS59B12.10012 1/23 3/41 1/412.32
50B60SS60B12.30012 1/23 3/41 1/413.00
50B70SS70B14.29012 1/23 3/41 3/418.16
50B72SS72B14.69012 1/23 3/41 3/419.48
50B76SS76B15.48612 1/23 3/41 3/421.00
50B80SS80B16.28012 3/44 1/41 3/424.74
50B84SS84B17.08012 3/44 1/41 3/425.50
50B95SS95B19.27012 3/44 1/41 3/432.00
50B96SS96B19.47012 3/44 1/41 3/432.92
50B112SS112B22.65012 3/44 1/41 3/442.00
★ Has recessed groove in hub for chain clearance.
Maximum bores shown will accommodate standard keyseat and setscrew over keyseat.
Slightly large bores are possible with no keyseat, shallow keyseat, or stescrew at angle to keyseat.
