KANA NK120-2B Sprockets

Model: 120B Sprocket

Item specifics

Material: Carbon Steel

Color: Natural

Surface Treatment: Blackening/Galvanizing/Phosphating

Accuracy: Precision teeth for optimum performance

Quality: Superior Metric Sprocket

Interchangeability: Directly interchangeable with other brands

Review

Description

About KANA NK120-2B Sprocket

Our KANA standard NK120B duplex sprockets are crafted from high-quality materials, these sprockets ensure optimal chain engagement, enhancing the longevity of both the chain and the sprocket itself. Trust CTS® for reliable and efficient power transmission solutions. Whether for industrial use or specialized machinery, our KANA standard duplex sprockets provide robust, dependable performance that meets rigorous standards.

For a quotation or other information, please get in touch with us and we will be happy to help you.

Quality Assurance:

ISO9001: 2015 and GB/T24001-2016 / ISO14001: 2015.

Features

High-precision Sprocket
Durable Sprocket
Directly interchangeable with other brands
OEM Sprocket

KANA 120B-2 Sprocket Dimension

CHAIN	Pitch	38.10 mm
	Internal width	25.40 mm
	Roller φ	22.23 mm
SPROCKET	Tooth width (T)	22.7 mm

B Type Solid KANA NK120-2B Sprocket Dimension Chart

B Type Weld KANA NK120-2B Sprocket Dimension Chart

Type	Teeth	Do	Dp	Bore d			BD	BL	Wt kg	Material
Type	Teeth	Do	Dp	Stock	Min	Max	BD	BL	Wt kg	Material
NK120-2B	10	140	123.29	26	28	55	80	100	8.00	C45 Solid Hardened teeth
	11	153	135.24	26	28	60	90	100	8.70
	12	165	147.21	28	30	66	100	100	9.20
	13	177	159.20	28	30	75	115	100	10.90
	14	190	171.22	28	30	80	120	100	11.40	C45 Solid
	15	202	183.25	38	40	80	120	100	13.20
	16	214	195.29	38	40	95	140	100	16.50
	17	227	207.35	38	40	95	140	100	19.00
	18	239	219.41	38	40	103	150	100	21.00
	19	251	231.48	38	40	103	150	100	23.00
	20	263	243.55	38	40	103	150	100	26.00
	21	276	255.63	38	40	103	150	100	28.00
	22	288	267.72	38	40	103	147	100	30.00	Fe360 Welding
	23	300	279.80	38	40	103	147	100	33.00
	24	312	291.90	38	40	110	157	100	31.00
	25	324	303.99	38	40	110	157	100	33.00
	26	337	316.09	38	40	110	157	100	35.00
	28	361	340.29	38	40	110	157	100	39.00
	30	385	364.50	38	40	110	157	100	43.90
	32	410	388.71	38	40	110	157	100	47.00
	35	446	425.04	38	40	110	157	100	56.80
	36	458	437.15	38	40	110	157	100	60.00
	38	483	461.38	38	40	110	157	100	67.00
