ANSI #120 Ball Bearing Idler Sprockets
ANSI #120 Ball Bearing Idler Sprockets
ANSI #120 Ball Bearing Idler Sprockets
Model
120 Idler Sprockets

Item specifics

Material
Carbon Steel
Material
Natural
Surface Treatment
Blackening/Galvanizing/Phosphating
Accuracy
Precision teeth for optimum performance
Quality
Superior ANSI Sprocket
Interchangeability
Directly interchangeable with other brands

Review

Description

About ANSI #120 Ball Bearing Idler Sprocket

The ANSI #120BB idler sprocket is distinguished by its incorporation of a ball bearing, ensuring smooth operation. Engineered with hardened teeth and a high-quality ball bearing, it fully complies with ANSI Standards. Crafted for durability and optimal performance, this #120 idler sprocket is constructed from top-quality steel and components, guaranteeing longevity in operation.


For inquiries or additional information about #120 ball-bearing idler sprockets, please don't hesitate to reach out to us. We're here to assist you.


Quality Assurance:

ISO9001: 2015 and GB/T24001-2016 / ISO14001: 2015.


Features

  • High-precision Sprocket
  • Durable Sprocket
  • Directly interchangeable with other brands
  • OEM Sprocket
ANSI #120 idler sprocket with ball bearing dimension chart

ANSI #120 Ball Bearing Idler Sprocket Technical Data

Part No.No. TeethBore SizeOutside Diameter(O.D)Dimension(T)Weight
120BB121240 mm6.500"0.942"5.80 LBS
