ANSI #35B Taper Bore Duplex Sprockets
ANSI #35B Taper Bore Duplex Sprockets
ANSI #35B Taper Bore Duplex Sprockets

ANSI #35B Taper Bore Duplex Sprockets

Model
35B-2 Sprockets

Item specifics

Material
Carbon Steel
Color
Black
Surface Treatment
Blackening/Galvanizing/Phosphating
Accuracy
Precision teeth for optimum performance
Quality
Superior ANSI Sprocket
Interchangeability
Directly interchangeable with other brands

Review

Description

About #35B Taper Bore Duplex Sprockets

#35B taper bore duplex sprockets provide unmatched convenience by enabling users to adjust bore sizes without the need to replace the entire sprocket assembly. Their hallmark feature lies in easy installation, facilitating swift adaptation to varying shaft diameters. With their versatility, duplex taper-bushed sprockets ensure compatibility with ANSI double strand chains. Crafted from high-quality steel, CTS® taper lock bore sprockets and taper bushings adhere to stringent ANSI requirements, guaranteeing durability and reliability in demanding operational environments.


For quotation or other information on #D35BTB sprockets, please contact us and we will be happy to help you.


Quality Assurance:

ISO9001: 2015 and GB/T24001-2016 / ISO14001: 2015.


Features

  • High-precision Sprocket
  • Durable Sprocket
  • Directly interchangeable with other brands
  • OEM Sprocket
35B taper lock bore duplex sprocket dimension chart

#35B Taper Bore Duplex Sprocket Technical Data

Pitch
3/8"
Roller φ
0.200"
Tooth width b1
0.162"
Tooth width B2
0.561"
Part No.No.
Teeth		BushingOutside Dia.（De）
inch		Pitch Dia.（Dp）
inch		Max.
Bore
inch		L
inch		  C
inch		TypeWeight (Approx.)
LBS
Rim OnlyBushing
Only
D35BTB19H1910082.4722.2781 7/81 53/64B.6.3
D35BTB20H2010082.5932.3971 7/81 15/16B8.3
D35BTB21H2110082.7132.5161 7/82  1/16B1.4.3
D35BTB22H2210082.8332.6351 7/82  3/16B1.7.3
D35BTB24H2412103.0742.8731 1/4 12  7/16B1.8.6
D35BTB262612103.3143.1111 1/4 12 5/8B2.0.6
D35BTB303016103.7933.5881 5/8 13 1/8B1.8.9
D35BTB323216104.0323.8261 5/8 13 1/4B2.0.9
D35BTB353516104.3924.1831 5/8 13 1/4B2.3.9
D35BTB404016104.9904.7861 5/8 13 1/4B2.9.9
D35BTB454516105.5885.3761 5/8 13 1/4B3.2.9
D35BTB484816105.9465.7341 5/8 13 5/8B3.5.9
D35BTB545416106.6636.4491 5/8 13 5/8B3.9.9
D35BTB606016107.3807.1651 5/8 13 5/8B4.9.9
D35BTB707016108.5758.3581 5/8 13 5/8B6.3.9
D35BTB808016109.7709.5521 5/8 13 5/8B7.9.9
D35BTB9696161011.68011.4611 5/8 13 5/8B9.9.9
D35BTB112112161013.59013.3711 5/8 13 5/8B10.9.9
