ANSI #60 Ball Bearing Idler Sprockets
ANSI #60 Ball Bearing Idler Sprockets
ANSI #60 Ball Bearing Idler Sprockets
Model
#60 Idler Sprockets

Item specifics

Material
Carbon Steel
Material
Natural
Surface Treatment
Blackening/Galvanizing/Phosphating
Accuracy
Precision teeth for optimum performance
Quality
Superior ANSI Sprocket
Interchangeability
Directly interchangeable with other brands

Review

Description

About ANSI #60 Ball Bearing Idler Sprocket

The ANSI #60BB idler sprocket is distinguished by its incorporation of a ball bearing, ensuring smooth operation. Engineered with hardened teeth and a high-quality ball bearing, it fully complies with ANSI Standards. Crafted for durability and optimal performance, this #60 idler sprocket is constructed from top-quality steel and components, guaranteeing longevity in operation.


For inquiries or additional information about #60 ball-bearing idler sprockets, please don't hesitate to reach out to us. We're here to assist you.


Quality Assurance:

ISO9001: 2015 and GB/T24001-2016 / ISO14001: 2015.


Features

  • High-precision Sprocket
  • Durable Sprocket
  • Directly interchangeable with other brands
  • OEM Sprocket
ANSI #60 idler sprocket with ball bearing dimension chart
ANSI #60 Ball Bearing Idler Sprocket Technical Data
Part No.No. TeethBore SizeOutside Diameter(O.D)Dimension(T)Weight
60BB11111/2"-0.459"-
60BB11115/8"-0.459"-
60BB12125/8"3.25"0.459"0.72 LBS
60BB13131/2"3.49"0.459"0.76 LBS
60BB13135/8"3.49"0.459"0.76 LBS
60BB15151/2"3.98"0.459"1.06 LBS
60BB15155/8"3.98"0.459"1.06 LBS
60BB17175/8"4.46"0.459"1.10 LBS
