Standard Clamping Plates for belt and HTD pulleys used for transmission industries
- Price
- US $0.5
- Model
- YY
- MOQ
- 1 piece
Item specifics
- product name
- weld-on hubs
- colour
- silver
Review
Description
Clamping Belt Parts
Clamping plates for imperial pitch belts | ||||||||||||||
Belt Width(inches) | ||||||||||||||
Pitch | F | d | B | A | S | 025 | 037 | 050 | 075 | 100 | 150 | 200 | 300 | 400 |
XL | 6 | 5.5 | 3.5 | 42.5 | 8 | 25.5 | 28.5 | 32 | 38 | 45 | - | - | - | - |
L | 8 | 9 | 5 | 76.5 | 15 | - | - | 39 | 45 | 51.5 | 64 | 77 | - | - |
H | 10 | 11 | 9 | 106.9 | 22 | - | - | 45 | 51 | 57.5 | 70 | 83 | 108 | 134 |
Clamping plates for HTD pitch Belts | ||||||||||||||
Belt Width(inches) | ||||||||||||||
Pitch | F | d | B | A | S | 6 | 9 | 10 | 15 | 20 | 25 | 30 | 40 | 50 |
5M | 6 | 5.5 | 3.25 | 41.5 | 8 | 25 | 28 | 34 | 44 | |||||
8M | 8 | 9 | 5 | 66 | 15 | 35 | 40 | 45 | 55 | 75 | ||||
14M | 10 | 11 | 9 | 116 | 22 | 56 | 71 | |||||||
Material: Steel or Aluminium
Treatment: Usually no treatment
Description: Clapming Belt Plates also called the Fixing Plates, which are used to join the belt ends in linear positioning and vertical lift applications where the belt moves bi-directionally between the pulleys on a horizontal or vertical plane.
Availability:
* Standard standard weld-on hubs
* OEM standard weld-on hubs
High Performance:
√Strong Ultimate tensile strength√Perfect surface treatment
√Durable,Flexible
Quality Assurance:
ISO9001: 2015 and GB/T24001-2016 / ISO14001: 2015.
√Corrosion resistance
√Durable, Robust and Reliable
√Bad condition resistance
√Lower weight--high speed
Application industries:
√Manufacturing
√Agriculture
√Building Material
√Oil and Gas
√Technology and Science
Package:
Plastic bag+Neutral box +Plywood box
YQ-CHINATRANSMISSION European Clamping Plates are widely used in Agriculture,Printing,Chemical,Food and Beverage,General Machinery,Oil and Gas,Packaging and Logistics,Paper Industry,Textile industry,Woodworking Machinery and so on.
The biggest characteristic is that the chains can be customized in different standard and materials according to your requirements. Made from the steel and the up-to-date skills as well as precision procedures, the high quality roller chain can withstand strong pressure and high temperature.
Durable standard weld-on hubs
