Price
US $0.5
Model
667X-ASF3
MOQ
1 piece

Item specifics

Model
667X-ASF3
Color

Review

Description

No.662F1/667X-ASF3 Dimensions
Steel Pintle Chains Specifications
Chain No.
Pitch
(mm)
Width between inner plates
(mm)
Inner plate depth
(mm)
Attachment dimension G
(mm)
Attachment dimension F
(mm)
Attachment dimension
 t
        (mm)
Attachment dimension
h4
(mm)
Tensile strength
kN/lbf
662F1
42.27
26.6
18.8
19.0
343.5
5.0
4.40
37.80/8597
667X-ASF3
57.15
26.6
23.8
38.0
514.4
7.0
0.00
66.70/14994
Product Information

The products are made of high quality alloy steel production. The plates are punched and squeezed bores by precision technology. The pin, bush, roller are machined by high-efficiency automatic equipment and automatic grinding equipment, then through heat treatment of carburization, carbon and nitrogen protection mesh belt furnace, surface blasting process etc. Made from the steel and the up-to-date skills as well as precision procedures, the steel pintle chains can withstand strong pressure and high temperature.



Availability:

* Standard chains

* Customized chains







Quality Assurance:

ISO9001: 2015 and GB/T24001-2016 / ISO14001: 2015.






High quality:

Corrosion resistance

Durable, Robust and Reliable

Bad condition resistance

Lower weight--high speed







Services:

Surface treatment

Hardened teeth

Serious quality control





Application industries:

Manufacturing

Agriculture
Building Material
Oil and Gas

Technology and Science

……
