Efficient High Quality Sewage Disposal Chains for Sewage Disposal transmission chain and enguneering chain From China
- Price
- US $0.5
- Model
- P609.6F1/P609.6F2/M112GA2F2-PA6-200
- MOQ
- 1 piece
Item specifics
- Product name
- Sewage Disposal Chains
- Model
- P609.6F1/P609.6F2/M112GA2F2-PA6-200
Review
Description
Chain No. | pitch (mm) | roller diameter d1 max (mm) | width between inner plate(mm) | pin dimension d2 (mm) | pin dimension L (mm) | plate dimension h2 (mm) | plate dimension t (mm) | plate dimension L1(mm) | tensile strength (kN/lbf) | weight per meter(kg/m) |
P609.6F1 | 609.60 | 95.25 | 41.65 | 31.75 | 107.80 | 69.85 | 9.50 | 304.80 | 230.0/51704 | 16.77 |
P609.6F2 | 609.60 | 101.60 | 39.69 | 30.73 | 84.30 | 76.20 | 9.50 | 292.10 | 80.0/17984 | 17.35 |
M112GA2F2-PA6-200 | 200.00 | 60.00 | 32.00 | 15.00 | 64.50 | 40.00 | 6.00 | 70.00 | 112.0/25178 | 5.30 |
The efficient durable sewage disposal chains are made of high quality alloy steel production. The plates are punched and squeezed bores by precision technology. The pin, bush, roller are machined by high-efficiency automatic equipment and automatic grinding equipment, then through heat treatment of carburization, carbon and nitrogen protection mesh belt furnace, surface blasting process etc. Made from the steel and the up-to-date skills as well as precision procedures, the flexible sewage disposal chains can withstand strong pressure and high temperature.
Availability:
* Standard chains
* Customized chains
Quality Assurance:
ISO9001: 2015 and GB/T24001-2016 / ISO14001: 2015.
High quality:
√Corrosion resistance
√Durable, Robust and Reliable
√Bad condition resistance
√Lower weight--high speed
Services:
√Surface treatment
√Hardened teeth
√Serious quality control
Application industries:
√Manufacturing
√Agriculture
√Building Material
√Oil and Gas
√Technology and Science
……
