European Standard Stock bore platewheel 085 sprocket platewheel

Group Stock bore platewheel
PriceUS $0.5 / piece
Min. Order 1 piece
Terms of Payment L/C, D/A, D/P, Western Union, MoneyGram, T/T, Paypal
Update Time 2020-09-17
Item specifics
namesprocket
colorsilver
  • Description
  • Product review
Roller Chain Sprocket - European Standard Series - 085A roller chain sprocket dimensions
ISO Roller Chain Sprockets Specifications
CHAIN SPROCKET
mm
ROLLER CHAIN
mm
Tooth Width B1
5.9
Chain Pitch
12.7
Hub Configuration
B
Roller Dia
7.75
Tooth Width B2
Chain Number
085
Tooth Width B3
Number of Chain Rows
1-2-3
Number of Teeth
8 - 125
Hardened Teeth
Up to customer
European Standard sprocket
Bore Type
Stock Bore
Min bore size
10
Max bore size
16
Product Information

YQ-CHINATRANSMISSIONS are able to provide high quality standard chain and sprocket,

include 085 chain sprocket (12.7 pitch chain sprocket).

Example:

10 tooth sprocket 085 chain.

15 tooth sprocket 085 chain.

30 tooth sprocket 085 chain.

72 tooth sprocket 085 chain...


Quality Assurance:

ISO9001: 2015 and GB/T24001-2016 / ISO14001: 2015.


High quality:

Corrosion resistance

√ Durable, robust and reliable

√ Bad condition resistance.

Adapted to:

* roller chains based on the requirements of ISO/R 606

* all sprockets with pilot bore

* available with type A platewheels,simplex roller chain sprockets,duplex roller chain sprockets,triplex roller chain sprockets,four strand roller chain sprocket

* material used for chain sprocket carbon steel 45

* heat treatment and special surface treatments are available on request:

black oxide sprocket with teeth hard



YQ-CHINATRANSMISSION ansi transmission chains and sprockets are widely used in Agriculture,Printing,Chemical,Food and Beverage,General Machinery,Oil and Gas,Packaging and Logistics,Paper Industry,Textile industry,Woodeworking Machinery and so on.


The biggest characteristic is that the sprockets can be customized in different standard and materials according to your requirements. Made from the steel and the up-to-date skills as well as precision procedures, the high quality sprockets can withstand strong pressure and high temperature.
