Transmission roller chain- 04C-1/25-1 short pitch roller chain Dimensions
- Price
- US $0.5
- Model
- 25 roller chain
- MOQ
- 1 meter
Item specifics
- name
- chain
- color
- grey
Review
Description
TRANSMISSION CHAIN
|
mm
|
mm
|
|
Chain Number | 25 | Pin Diameter | 2.31 |
Pitch(P)
|
6.35
|
Pin Length
|
7.9-8.4
|
Roller Diameter(d1)
|
3.3
|
Inner Plate Depth
|
6
|
Roller width(b1)
|
3.18
|
Plate Thickness
|
0.8
|
Tensile Strength(KN/LBF) | 3.5/795 | Number of chain row | 1-2-3 |
YQ-CHINATRANSMISSIONS are able to provide high quality ansi standard roller chain,
transmission chain manufacture,
include #25 roller chain (1/4 pitch chain).
Quality Assurance:
ISO9001: 2015 and GB/T24001-2016 / ISO14001: 2015.
High Quality:
√Corrosion resistance
√Durable, Robust and Reliable
√Bad condition resistance
√Lower weight--high speed
Application industries:
√Manufacturing
√Agriculture
√Building Material
√Oil and Gas
√Technology and Science
Package:
Plastic bag+Neutral box +Plywood box
Adapted to:
* roller chains based on the requirements of ANSI B29.1
* Roller chain components are shot peened for greater fatigue resistance
* available with single strand roller chain,double strand roller chain,triple strand roller chain,four strand roller chain
* material used for roller chain 40mn
* heat treatment and special surface treatments are available on request
YQ-CHINATRANSMISSION ansi transmission chains and sprockets are widely used in Agriculture,Printing,Chemical,Food and Beverage,General Machinery,Oil and Gas,Packaging and Logistics,Paper Industry,Textile industry,Woodeworking Machinery and so on.
The biggest characteristic is that the pulley can be customized in different standard and materials according to your requirements. Made from the steel and the up-to-date skills as well as precision procedures, the high quality pulley can withstand strong pressure and high temperature.
